Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
Special Price $1,356.78 Regular Price $2,324.70 -42%
Availability: Available for Order
SKU
FL-ES-200X
Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
| Manufacturer Part Number | ES-200X |
|---|---|
| Features | Product OverviewES-200X fire alarm control panels (FACPs) come with a pre-installed communicator and support up to 198 addressable devices (99 detectors and 99 modules). With an extensive list of powerful features, these FACPs are just like other & Fire-Lite® & addressable products, yet fit into applications previously served only by conventional panels. The pre-installed IPOTS-COM is a dual technology (POTS and IP) communicator. The POTS transmits system status (alarms, troubles, AC loss, etc.) to a central station via the public switched telephone network. The IP communicator’s internet monitoring capability sends alarm signals over the internet saving the monthly cost of two dedicated business telephone lines. Although not required, the secondary telephone line may be retained providing backup communication over the public switched telephone line. Optional cellular reporting is available. Remote and local programming of the control panels is possible using the FS-Tools upload/download utility. Programming databases can be uploaded/downloaded via the panel’s USB port (and USB cable) or via an Ethernet connection using the IPOTS-COM communicator. The USB port also allows for the download or upload of the entire program, history file, walk-test data, current status, and system voltages by means of a USB flash drive. The power supply and all electronics are contained on a circuit board supported on a new quick-install chassis and housed in a metal cabinet.
What’s Included
Main Features
General InformationName: Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
Category: Fire-Lite Alarms by Honeywell, Fire, Fire Control Panels, Fire Alarm Control Panels, ADI Pro Rewards
UPC Code: 783008112608
Country of Origin: United States. Country of origin is subject to change.
|
Write Your Own Review
Product Overview
ES-200X fire alarm control panels (FACPs) come with a pre-installed communicator and support up to 198 addressable devices (99 detectors and 99 modules). With an extensive list of powerful features, these FACPs are just like other & Fire-Lite® & addressable products, yet fit into applications previously served only by conventional panels. The pre-installed IPOTS-COM is a dual technology (POTS and IP) communicator. The POTS transmits system status (alarms, troubles, AC loss, etc.) to a central station via the public switched telephone network. The IP communicator’s internet monitoring capability sends alarm signals over the internet saving the monthly cost of two dedicated business telephone lines. Although not required, the secondary telephone line may be retained providing backup communication over the public switched telephone line. Optional cellular reporting is available. Remote and local programming of the control panels is possible using the FS-Tools upload/download utility. Programming databases can be uploaded/downloaded via the panel’s USB port (and USB cable) or via an Ethernet connection using the IPOTS-COM communicator. The USB port also allows for the download or upload of the entire program, history file, walk-test data, current status, and system voltages by means of a USB flash drive. The power supply and all electronics are contained on a circuit board supported on a new quick-install chassis and housed in a metal cabinet.
What’s Included
- ES-200X Intelligent Addressable FACP with Communicator
- Plastic Bag Containing Screws, Cables, Key
Main Features
- Upload/Download panel programming database and flash firmware with USB thumb drive
- Addressable multi-criteria detector (smoke, heat, CO) with programmable response
- Addressable Sounder Bases
- Two programmable function keys
- Built in Class-A capability for all 4 NACs; no optional card required
- Trouble indication for SLC devices not programmed
- Automatic discovery of "relay" versus "NAC" type control modules during auto-programming of SLC loop
- Integrated SWIFT display driver and annunciator built-in to panel
- Auto-programming (learn mode) reduces installation time
- Two built-in, independently programmable, built-in Style Z (Class A) or Style Y (Class B) NACs
General Information
Name: Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
Category: Fire-Lite Alarms by Honeywell, Fire, Fire Control Panels, Fire Alarm Control Panels, ADI Pro Rewards
UPC Code: 783008112608
Country of Origin: United States. Country of origin is subject to change.
