Silent Knight 006820 Silent Knight 6820 1110-Point Addressable Fire Alarm Control Panel (Replaces 5820XL)
Special Price $1,809.20 Regular Price $3,280.00 -45%
Availability: Available for Order
SKU
SIL-6820
Silent Knight 006820 Silent Knight 6820 1110-Point Addressable Fire Alarm Control Panel (Replaces 5820XL)
Silent Knight 006820 Silent Knight 6820 1110-Point Addressable Fire Alarm Control Panel (Replaces 5820XL)
| Manufacturer Part Number | 6820 |
|---|---|
| Features | Product OverviewThe 6820 is the latest intelligent addressable FACP (Fire Alarm Control Panels) from Silent Knight and is a direct replacement for the 5820XL FACP. The FACP has one built-in SLC (signaling line circuit), which can support 159 System Sensor® SK detectors and 159 SK modules, or 127 Hochiki® SD protocol devices. Additional SLC loops can be added for a maximum of 1110 (SK) or 635 (SD) points per panel.
Main Features
General InformationName: Silent Knight 006820 Silent Knight 6820 1110-Point Addressable Fire Alarm Control Panel (Replaces 5820XL)
Category: Silent Knight by Honeywell, Fire, Fire Control Panels, Fire Alarm Control Panels, ADI Pro Rewards
UPC Code: 783196014227
|
Write Your Own Review
Product Overview
The 6820 is the latest intelligent addressable FACP (Fire Alarm Control Panels) from Silent Knight and is a direct replacement for the 5820XL FACP. The FACP has one built-in SLC (signaling line circuit), which can support 159 System Sensor® SK detectors and 159 SK modules, or 127 Hochiki® SD protocol devices. Additional SLC loops can be added for a maximum of 1110 (SK) or 635 (SD) points per panel.
Main Features
- Complies with UL 864 10th Edition and UL 2572 2nd Edition Standards
- Expandable SLC loops to 1110 (SK) or 635 (SD) point capacity
- Six Flexput circuits for NAC outputs or auxiliary power
- Selectable strobe synchronization for Amseco®, System Sensor, Wheelock®, and Gentex® devices
- Built-in DACT with IP and optional cellular reporting
- Built-in USB interface for quick and easy programming
- JumpStart® auto programming reduces installation time
- 999 software zones and 999 output groups for flexible design options
- 23 preset notification cadence patterns (including ANSI® 3.41)
- Allows up to 24 SBUS devices
General Information
Name: Silent Knight 006820 Silent Knight 6820 1110-Point Addressable Fire Alarm Control Panel (Replaces 5820XL)
Category: Silent Knight by Honeywell, Fire, Fire Control Panels, Fire Alarm Control Panels, ADI Pro Rewards
UPC Code: 783196014227
